ALPRO AL111AS ANSI SHORT ELECTRIC STRIKE

The Alpro AL110 electric strikes are ANSI style electric strikes complete with stainless steel short or long faceplates for use in metal or timber door applications. This AL110 electric strike is 12/24v selectable with a stainless steel faceplate & striker and a holding force of 1,750kg (3,860lbs). 35mm overall depth compact cast aluminium body & has a deep jaw which accepts a 13mm latch bolt. Low current consumption – 200mA – 12vDC / 100mA – 24vDC continuous (+15%). Simple fail safe/fail secure changeover. AC compatibility (with RM1) – The rectifier sounder module enables operation with AC voltages. The sounder can be set for either buzzing or silence with both AC & DC voltages. The Alpro RM1 unit is continuously rated – max 1 amp. Approvals – CE – BS EN 50081:1 & EN 50082:1.
